General Characteristics

ContactsTerminationWire gauge in mm²Wire gauge in AWGShell protectionMechanical operationUpper temperatureLower temperture
4---IP67 / IP68>100 mating cycles+80℃-40℃

Electrical Characteristics

Rated voltageRated current(40℃)Contact resistanceInsulation resistance
630V12A≤3mΩ≥100MΩ

Materials

Pin contactSocket contactContact plating
CuZnCuSnAu
