HR 12 Pins Female Metal Assembly Connector

  • Order No.: 950112-21-003

  • Product No.: N / A

Return to List

General Characteristics

ContactsTerminationWire gauge in mm²Wire gauge in AWGShell protectionMechanical operationUpper temperatureLower temperture
12solder--IP67 / IP68>100 mating cycles+85℃-25℃

Electrical Characteristics

Rated voltageRated current(40℃)Contact resistanceInsulation resistance
140V2A≤3mΩ≥100MΩ

Materials

Pin contactSocket contactContact plating
CuZnCuSnAu
