M23 19Pins Female Straight Assembly Connector

  • Order No.: 230019-02-005

  • Product No.: N / A

Return to List

General Characteristics

ContactsTerminationWire gauge in mm²Wire gauge in AWGShell protectionMechanical operationUpper temperatureLower temperture
19crimp--IP69K>100 mating cycles+85℃-25℃

Electrical Characteristics

Rated voltageRated current(40℃)Contact resistanceInsulation resistance
150V16 * 3A + 16 * 3A≤5mΩ≥100MΩ

Materials

Pin contactSocket contactContact plating
CuZnCuSnAu
